  • 25 GPM - Fully Automatic Solids Transfer and Grease Separation Device (W-1250-AST)
  • 125 GPM - Fully Automatic Solids Transfer and Grease Separation Device

    • 125 GPM - Fully Automatic Solids Transfer and Grease Separation Device

    $10,615.00
    (No reviews yet) Write a Review
    SKU:
    W-1250-AST
    Shipping:
    Free Shipping
    Sales Tax Note:
    Sales tax will be added to orders shipped to NC and CA

    Product Description

    W-1250-AST Grease Removal for restaurantsThe W-1250-AST Automatic Grease Removal Device is capable of accepting up to a 125 GPM (7.89 l/s) flow.  The two center modules which comes with digital time control, heater assembly, and mechanized skimming assemble, automatically isolates trapped grease into grease collectors for easy disposal.  The Automatic Solids Transfer feature automatically empties incidental solids out of the solids chamber and down the sewer line.

    • Fully automatic self cleaning cycle. Removes collected grease & oils from tank without any operator assistance. Comes complete with two center lid assemblies with digital control interface and Grease Collector.
    • Constructed of corrosion resistant materials suitable for installation in virtually any location. Attractive sanitary Stainless Steel exterior.
    • Integrated Motor/Grease Outlet/Heater/Lid enables a fast, do-it-yourself unit operation reversal.
    • Compact footprint.
    • Two (2) No-Hub Connectors provided.
    • Versatile and compact, can either be floor mounted or used in a partially recessed installation
    • Automatic self-cleaning cycle runs without need of an operator’s assistance
    • Offers a 24-hour multi-event time control to process when it would be most convenient during the course of each day
    • Collection container can be taken off so that seized grease and oils can be dumped in your specified area
    • Motor location and the grease/oil sump outlet are reversible to accommodate your sink’s plumbing design



    Specs:

    Materials:       Exterior: 304 Stainless Steel, Bright Finish        Interior: Rotationally Molded Polyethylene
    Electrical:  115 VAC, 50/60 Hz, 1055 Watts (9.1 Amps)*
    Maximum Inlet Flow Rate:  125 GPM (7.89 l/s)
    Number of Skimming Wheels:  1
    Skimming Rate:  40 Pounds Per Hour (18.16 Kg Per Hour)
    Grease Retention Capacity:  300+ Pounds (136+ Kg)
    Eductor Pump Operation Water Requirements: 50 PSI min., 12 GPM (3.45 BAR min., 0.75 l/s)

    Big Dipper Model No. W-1250-AST, bright finish type 304 stainless steel exte- rior, rotationally molded polyethylene interior automatic self-cleaning grease and oil recovery separator(s) for floor mounted or partially recessed installation, rated at 125 gallons per minute (7.89 l/s) peak flow, 300 pounds (136 Kg) of grease capacity and including as an integral part of the unit, two rotating gear hydrophobic wheel assemblies for automatic grease/ oil removal, an integral flow control device, two self-regulating enclosed electric immersion heaters, a vessel vent, an integral gas trap, two integral programmable 24-hour multi-event time controls, field reversible motor locations, field reversible grease/oil sump outlets, quick release stainless steel lid clamps, a gasketted and fully removable 304 stainless steel lid, lift-out filter basket access, an eductor transfer pump controlled by repeat cycle timer, and two separate grease and oils collection containers. Eductor pump shall be supplied with a 0.5” female connector for attachment to facility-supplied water supply. Eductor pump shall be supplied with an approved vacuum breaker. Electric assembly shall be tested to comply with pertinent sections of the Standards for Safety ANSI/UL 73 and/or ANSI/UL 1004. Each electric motor equipped with overload protection.

    *Electrical Variations

    W-1250-AST: 115V 50/60Hz, 1055 Watts (9.1 Amps)
    W-1250-AST-E: 230V 50/60Hz, 1055 Watts (4.6 Amps)Unit may be improperly listed as W1250AST, W-1250AST, W1250-AST, W-1250, W1250, 1250-AST or 1250AST


    Click here to DOWNLOAD the full Spec Sheet and Installation Instructions






    Free Shipping

    QUALIFIES FOR FREE SHIPPING VIA LTL IN CONTIGUOUS US ONLY.  FOLLOWING PURCHASE, CONTACT Drain-Net Technologies AT 1-844-564-9216 TO VERIFY SHIPPING DETAILS AND SCHEDULE DELIVERY.
